Excavator bearing SF3607VPX2

Time: 2014-03-28 Click：2925

Product name： Excavator bearing - precision angular contact ball bearing

Product description： Excavator bearings are used at lot of heavy machinery such as :Komatsu and KOBELLO,Daewoo, Kato, and Sumitomo, Hyundai , Hitachi, Caterpillar , volvo etc

Excavator specialized angular ball bearing are used for the application of excavator machinery.

This kind of angular contact ball bearing has big contact angle(40 degree),so can undertake big axial load,and aslo axial and radial allied load.Moreover it can carry heavier load capacity

than the same size bearings because it has more balls inside.It is widely used for all imported excavator.

Main dimensions:

d ^mm⁄_inch	D ^mm⁄_inch	T ^mm⁄_inch	B ^mm⁄_inch	Mass ^kg⁄_lb ➁
180.000	225.000	21.500	10.250	1.180
7.0866	8.8583	0.8465	0.4035	2.601

Drawing ➂:

SF3607VPX2

BEARING	DIMENSION
BEARING	d	D	B
BA152-2036	152	203	26
BA222-1WSA	222	273	26
BA220-6SA	220	276	26
BA240-3ASA	240	310	33.5
SF4815VPX1	240	310	34
SF4831PX1	240	310	33.4
AC5033	250	330	37
AC5836	289	355	34
AC463240	230	320	40
HS05145	117	145	14
HS05154	126	154	14
HS05383	320	383	30
MC6034	300	340	18
180BA-2256	180	225	22
B-SF4454PX1	220	295	33
BA260-4	260	340	38
AC4629	230	290	27
BA230-7ASA	230	300	35
SF3607	180	225	15
BA180-4WSA	180	250	33
AC4531	225	315	36
AC4631	230	310	39
BA4852PX1	240	310	33
R196Z-4	196.85	241.3	17.462/23.812
180N19W	180	250	33
200BA27V-2	200	270	33
210BA29V	210	295	35
AC423040-1	210	300	40
AC4630	230	300	35
BA280-2SA	280	370	40
BA300-4WSA	300	395	50
BD130-1SA	130	166	34
BN220-1	220	280	28
CR4411PX1	220	290	32
CR6016PX1	300	380	38
SF2812PX1	140	175	17.5
SF3227PX1	160	200	20
SF4007PX1	200	250	25
SF4019PX1	200	260	30
BA230-2A	230	320	40
