Type

Class B

4   1/4"×8"

inch

4

6.5

4.5

5

14.8

TAROL4X8-U-JP

HM120848

mm

101.6

165.1

114.3

127

HM120817XD

Class C

5"×9"

inch

4.6885

7.6875

5.625

5.875

24.8

TAROL5X9-U-JP

BT2-8735   BB

HM124646

mm

119.088

195.263

142.875

149.225

HM124618XD

Class D

5   1/2"×10"

inch

5.188

8.1875

6

6.375

27.3

TAROL5-1/2X10-U-JP

BT2-8547   BB

HM127446

mm

131.775

207.936

152.4

161.925

HM127415XD

Class E

6"×11"

inch

5.687

8.6875

6.437

7.03   - 7.032

34.9

TAROL6X11-U-JP

BT2-8516   BB

HM129848

mm

144.475

220.663

163.51

178.562   - 178.613

HM129814XD

Class F

6   1/2"×12"

inch

6.1879

9.9375

7.25

7.53   - 7.532

52.9

TAROL6-1/2X12-U-JP

BT2-8512   BB

HM133444

mm

157.175

252.413

184.15

191.262   - 191.313

HM133416XD

Class G

7"×12"

inch

6.9995

10.875

7.312

8   - 8.002

60.1

TAROL7X12-U-JP

BT2-8609   BB

HM136948

mm

177.878

276.225

185.725

203.2   - 203.251

HM136916XD
